Description
Dry screw and roots booster combination. Pumping speed 1900-2200 m³/h, ultimate pressure 10⁻³ mbar. Water-cooled, 15 kW, IP21D, 64 dB(A), 515 kg. An ATEX-certified Hazloc variant is available separately.
Edwards GXS250/2600 Dry screw pump
Price range: £65,365.00 through £78,439.00
GXS250/2600F HV MD+ SE SK
Additional information
| Brand | Edwards |
|---|---|
| Pump type | Dry screw pump |
| Variant | GXS250/2600 – Dry Screw Pump, 3Ph 380-460V 50/60Hz, Medium Duty + (High Flow Purge/Solvent Flush) 18-52 slm, GXS250/2600 – Dry Screw Pump, 3Ph 200-230V 50/60Hz, Medium Duty (SSP+HVP+Inlet+GB+Exh PM) 18-52 slm, GXS250/2600 – Dry Screw Pump, 3Ph 200-230V 50/60Hz, Medium Duty + (High Flow Purge/Solvent Flush) 18-52 slm, GXS250/2600 – Dry Screw Pump, 3Ph 380-460V 50/60Hz, Medium Duty (SSP+HVP+Inlet+GB+Exh PM) 18-52 slm, GXS250/2600 – Dry Screw Pump, 3Ph 380-460V 50/60Hz, Light Duty (SSP+HVP) – 12 slm, GXS250/2600 – Dry Screw Pump, 3Ph 200-230V 50/60Hz, Light Duty (SSP+HVP) – 12 slm |
| Cooling method | Water Cooling |
| Power supply voltage | 3Ph 380-460V 50/60Hz, 3Ph 200-230V 50/60Hz |
| Connection inlet/outlet flange | DN 160 ISO-F / DN 40 ISO-KF (NW40), DN 160 ISO-F / DN 50 ISO-KF (NW50) |
